․Specifications
|
Item / Type
|
CS-K□
|
CS1-K□
|
|
Wiring Method
|
2-Wire Type
|
|
Power Voltage
|
DC3 ~ 30V, AC85 ~ 115V ( r.m.s )
|
DC5 ~ 28V, AC85 ~ 115V
|
|
Load Ampere
|
DC40mA, AC25mA max.
|
DC40mA, AC25mA max.
|
|
Internal Voltage Drop
|
0.2mV max. at 40mA
|
2.2V max.at 40mA
|
|
Leakage Current
|
OmA
|
|
Response Time
|
1ms max.
|
|
Insulation Resistance
|
100MΩmin. DC500V Test The Joint Between The Unit And Wire End
|
|
Insulation Voltage Strength
|
AC500V ( 50/60 Hz ) One Minute
Test The Joint Between This Unit And Wire End
|
|
Impact Resistance
|
294.2m/s 30G Non-Reciprocating Impact
|
|
Vibration Resistance
|
88.3m/s 9G Double Amplitudes 1.5mm 10 ~ 55Hz.
|
|
Protection Configuration
|
IP67 EC Spec. , JIS C0920 Waterpro Of Type
|
|
Operation Indicator
|
Red LED Lights Up When at ON
|
|
Lead Wire
|
PVC 0.2SQ x 2Cores x Brown , Blue x1
|
|
Service Life
|
5 x 10 Times min
|
|
Operating Temperature
|
0 ~ 60°C
|
|
Storage Temperature
|
-10 ~ 70°C
|
|
Weight
|
20g Wire length: For 1000mm Occasion
|
․Internal Circuit
|
CS-K□
|
CS1-K□
|
|
|
|
․Dimension Diagram （Unit:mm）
|
CS-K□
|
CS1-K□
|
|
|
|
|
